REXON Automatic SF6 Purity Analyzer
  • REXON Automatic SF6 Purity Analyzer

REXON Automatic SF6 Purity Analyzer

Place of Origin China
Brand Name REXON
Certification CE, ISO, SGS, CCC
Model Number Model RNSFC
Product Details
Function:
SF6 Purity Measuring
Measurement Range:
0 ~ 100% (SF6 Percentage)
Resolution:
0.01%
Sampling Flow:
0.5 ~ 0.8l/min
Response Time:
15s (90%)
Display:
LCD Touch Screen
Power Supply:
220V±10%、50Hz
Dimension:
320×270×140mm
Guarantee Period:
2 Years
Product Description

Description

RNSFC SF6 gas purity analyzer is the latest intelligent measuring instrument developed by our company. This product adopts the colour highlight LCD touch screen as the man-machine interface, the full Chinese interface is convenient for operation, and all kinds of data are displayed in real-time. The full touch screen with high precision and fast response is used as man-machine input, and a variety of functions can be switched freely. The built-in high-capacity rechargeable lithium battery pack provides ultra-long standby time. The standard USB interface is configured, and the historical data can be exported to the USB flash disk through the interface.
The instrument adopts the most advanced microthermal conductivity sensor with temperature compensation to provide users with a simple on-site detection method of SF6 purity. It is mainly used to measure the purity (percentage content) of SF6 gas in bottled SF6 gas, SF6 switches and other equipment. It can also be used in applications with several background gases (special requirements are required).



Technical Parameters

Measurement range: 0 ~ 100% (SF6 percentage)

Measurement accuracy: ± 0.1 ℃ (within 90% ~ 100% range)
Resolution: 0.01%
Sampling flow: 0.5 ~ 0.8l/min
Response time: 15s (90%)
Sampling system: built-in pressure stabilizing valve, filter and electronic flowmeter
Display mode: colour touch screen display, all English interface, with backlight
Output interface: USB2.0 specification
Power supply: built-in rechargeable lithium battery (with charging protection device), which can work continuously for 10 hours
Operating temperature: - 40 ℃ ~ + 80 ℃
Size: 320 (mm) × 270(mm) × 140(mm)
