PLC Fully Automatic Lubricating Oil Filtration Machine Dissolved Water Removal Purifier

Application

REXON PLC Fully Automatic Lubricating Oil Filtration Machine Dissolved Water Removal Purifier TYA-20(1200LPH), which is applied to recover and purify various industrial lubricating oils such as hydraulic oil, mechanical oil, coolant oil, gear oil, heat treatment oil and so on. It can rapidly remove water and moisture(free water, dissolved water and trace water), impurities, tiny particles, dust, metal sludge, etc from contaminated lube oil, so to clean oil and regenerate oil. After the purification process, the used oil can get new oil lie with qualified property to be used again as new oil.

Features

1. With the strong ability to filter the impurity, filter the particles completely.
2. Advanced dielectric condensation device, which performs a good cooling function on the machine.
3. This machine installs the new pressure protector, which can control the machine running automatically; also it can drain water online by the water–separator device. So it is easy to control this machine.
4. Adopt high-quality filter materials, which have a good function in anti-corrosive, thermostable, and mechanical strength. Especially, the precision of eliminating impurities is high and the service life is long. Also, it has a large volume for storing the impurities.
5. The unique degas and dewater system: Using the Stereo-Evaporation technical, which can separate the water and gas from the oil quickly by the Multi-level water-oil separation technology.
6. It takes a safe electric control system and inter-lock system, that can keep the machine working normally. No matter which part of the machine works wrong, the machine will stop automatically.

7. Equipped with the PLC fully automatic control system and touch screen, it allows the machine can be started by just one-touch operation, and even no operator needed after runs stably.

Advantages

The PLC fully automatic operation system make this purifier machine more intelligent and convenient to operation, such as set machine parameters on the screen, including heating temperature, running time, oil moisture data, fault record, etc. And also can operate the equipment fully automatically through one-touch operation, save manpower and time.

Technical Parameters
